Windows

The Aluprof MB-104 passive profile fully meets the strict requirements of passive construction and thus protects your wallet and the environment in the long term. Due to the exceptional frame depth of 95 mm and a sash depth of 104 mm, the aluminum profile has excellent values in terms of wind load, air permeability and tightness against driving rain. The tightness and thermal parameters are even above the required standard.

In addition to the outstanding functionality, this system promises an extremely elegant appearance and creative diversity. In addition to the well-known RAL colors, wonderful wood looks are also possible. The Aluprof MB-104 Passive system are characterized by a highly stable construction, minimal maintenance effort and exceptionally high quality.

• 3-chamber system with high thermal separation
• Frame depth of 95 mm
• Wing construction depth of 104 mm
• Maximum glass thickness up to 81 mm
• Thermal barrier MB-104 Passive with excellent thermal insulation

Your benefits from the aluminum window MB-104 Passive

Profile:
Excellent heat insulation thanks to the 3-chamber system with a centrally wide insulation chamber.

Glazing:
Strong insulating glazing in double to quadruple glazing. Optional: Equipment with functional glasses for higher sound insulation and security possible.

Seals:
Highly efficient sealing system for exceptional thermal insulation and tightness parameters.

Systems:
Depending on the thermal insulation required, the system is available in two versions: SI and AERO. With the Aero system, the spaces between the heat-insulating intermediate layers are filled with airgel inserts.

Other models from the manufacturers mentioned are also available on request.

The MB-86 system is the innovative and world's first window and door system in which airgel (a material with optimal thermal insulation) is used. Outstanding thermal insulation performance is the hallmark of the Aluprof MB-86 series.

Three construction variants (ST, SI and AERO) allow you to choose the best solution that exactly meets your requirements and needs. In addition, the profiles have exceptionally high durability, which enables the construction of large and heavy windows.

• 3-chamber system with high thermal separation
• Frame depth of 77 mm
• Wing depth of 86 mm
• Center seal made up of several components
• Maximum glass thickness up to 67.5 mm

Your advantages from the aluminum window MB-86

Profile:
3-chamber system with insulating bars made of glass fiber reinforced polyamide for excellent thermal insulation.

Glazing:
Strong insulating glazing in double to quadruple glazing. Optional equipment with functional glasses for higher sound insulation, safety and more.

Seals:
Reliable sealing system with a central seal made of two-component EPDM as well as disc and stop seals made of synthetic EPDM.

Fittings:
High-quality MACO MULTI MATIC fittings with anti-burglary mushroom cams for optimum security and a mishandling device for more convenience.

Very good insulation values and the plus in security predestine this system for use in new buildings.

The IDEAL 8000 windows have a 6-chamber system with a construction depth of 85mm and 3 sealing levels (MD).

As the third seal in the window frame, the all-round central bar ensures better thermal insulation values on the one hand and prevents the sash from being prized open quickly on the other.

The interaction of the large construction depth with 6-chamber technology, the insulating heat protection glazing and the filigree design of the window profile has resulted in a window system that is both energetically and optically at a high level.

The IDEAL 8000 Aluskin variant, with an additional aluminum facing shell, is offered for a particularly large variety of colors and effective weather protection. The Classic and Round Line variants are available for the glazing beads.

• 6-chamber system with 85mm overall depth
• 3 sealing levels made of EPDM
• Triple glazing
• Disc packs up to 51mm
• MACO Multi Matic security fitting
• Optimum burglary protection and thermal insulation thanks to the third sealing level with all-round central bar
• Uf value: 1.0 W/m2K
• Best Uw value: 0.67 W/m2K
• Security up to RC3
• Sound insulation up to 48db

Your advantages from the plastic window Aluplast IDEAL 8000

Profile:
High-quality 6-chamber profile with an installation depth of 85 mm for excellent security and thermal insulation.

Glazing:
The glazing can be selected from a variety of special glasses with a glass thickness of up to 51mm.

Seals:
The plastic profiles have 3 sealing levels with a middle seal (MD) made of EPDM.

Fitting:
Security fittings from MACO Multi Matic. For increased durability, the fittings work in the so-called dry chamber.

Other models from the manufacturer mentioned are also available on request.

This system is suitable for single-family house construction as well as for renovations. The window profiles have a 5-chamber system with a construction depth of 70mm and 2 sealing levels with rebate seal (AD), which increase the room climate and protect against the effects of the weather. Depending on the version, you can choose between recessed and semi-recessed sash profiles and glazing beads from the Classic-Line (CL), Soft-Line (SL) and Round-Line (RL) design series. There are also several ways to increase the functionality and security of the windows. By default, the IDEAL 4000 plastic windows are equipped with a burglary-resistant mushroom head lock with pressure control.

An important part of the MACO Multi Matic hardware is the sash pressure against the airgap. In addition to burglary protection, this also ensures the tightness and easy functionality of the window sash. Depending on which security class is required, the number of burglar-resistant security mushroom cams can be increased, and a lockable window handle and anti-drill protection can be configured. On request, the windows can also be provided with security classes RC 1 (formerly WK1) or RC 2 (formerly WK 2).

• 5-chamber system with 70mm depth
• 2 sealing levels made of EPDM
• Double / triple glazing
• Disc packs up to 41mm
• MACO Multi Matic security fitting
• Optional: IDEAL 4000 NEW with a frame depth of 85mm
• Uf value: 1.3 W/m2K
• Best Uw value: 0.76 W/m2K
• Security up to RC2
• Sound insulation up to 45db

Your benefits from the Aluplast IDEAL 4000 plastic window

Profile:
High-quality 5-chamber profile with an installation depth of 70 mm for proven stability and high thermal insulation.

Glazing:
The glazing can be selected from a variety of special glasses with a glass thickness of up to 41mm.

Seals:
The plastic profiles have 2 stop seals (AD) made of EPDM, which offer optimal protection.

Fitting:
Security fittings from MACO Multi Matic. A large reinforcement chamber with steel reinforcement also provides the appropriate statics.

Other models from the manufacturer mentioned are also available on request.

This class A plastic profile consists of 6 chambers. It has three sealing levels with a central seal, which ensures excellent thermal insulation. In addition, you can equip the window with triple or even quadruple glazing with a warm edge to really meet all the requirements for passive construction elements. Excellent fittings from MACO are used to ensure long-term functionality and the necessary security. Furthermore, this system impresses with all-round steel reinforcement and full frame reinforcement. The special feature is the narrow face width of only 118 mm with an installation depth of 92 mm. This significantly increases the incidence of light, which not only reduces energy costs, but also ensures a pleasant living environment.

• Class A 6-chamber system with a depth of 92mm
• 3 sealing levels made of EPDM
• Triple / quadruple glazing
• Disc packs up to 60mm
• MACO Multi Matic security fitting

Your benefits from the plastic window Salamander BluEvolution 92

Profile:
Class A 6-chamber profile with optimal thermal insulation and an installation depth of 92 mm for excellent energy efficiency.

Glazing:
The glazing can be selected from a variety of special glasses with a glass thickness of up to 60mm.

Seals:
The plastic profiles have 3 sealing levels with a middle seal (MD) made of EPDM.

Fitting:
Security fittings from MACO Multi Matic. For increased durability, the fittings work in the so-called dry chamber.

Other models from the manufacturer mentioned are also available on request.

With the multi-chamber system and double or triple insulating glazing, you save on heating costs and can also enjoy a healthy indoor climate. The Streamline windows have 2 sealing layers with stop seal (AD) that protect against the elements. The plastic frame has a construction depth of 76 mm. The durable surface is easy to clean. Depending on the version, you can choose between the Classic-Line (CL) and Round-Line (RL) design series. MACO Multi Matic fittings ensure lasting functionality and the necessary security. Thanks to a wide range of decorative films, you can give your windows a personal touch. Strong colors, wood looks and grains are available for this.

• 5-chamber system with a depth of 76mm
• 2 sealing levels made of EPDM
• Double / triple glazing
• Disc packs up to 48mm
• MACO Multi Matic security fitting

Your benefits from the plastic window Salamander Streamline 76

Profile:
High-quality 5-chamber profile with an installation depth of 76 mm for high thermal insulation and statics.

Glazing:
The glazing can be selected from a variety of special glasses with a glass thickness of up to 48mm.

Seals:
The plastic profiles have 2 stop seals (AD) made of EPDM, which offer optimal protection.

Fitting:
Security fittings from MACO Multi Matic. A large reinforcement chamber with steel reinforcement provides the appropriate statics.

Other models from the manufacturer mentioned are also available on request.

These energy-saving windows set new standards in terms of comfort, security, energy efficiency and design. With a construction depth of 82 mm and thermal insulation values up to passive house level (Uw ≤ 0.8 W/m²K), this system has all the properties that are necessary for pioneering energy-saving windows. A new sealing technology offers effective protection against moisture, drafts and noise.

These feel-good windows offer a wide range of possible uses and are suitable for both new builds and modernization projects. All window shapes – including pitched and arched windows – can be combined with this modular system and with style elements and sash bars.

• 7-chamber system for optimum insulation values
  slim 82 mm overall depth
• 3 sealing levels made of EPDM
• Double / triple glazing
• UF value = 1.0 W/m²K
• High-quality brand fittings
• Burglary protection up to resistance class RC 2
• Quality "Made in Germany"

Your benefits from the plastic window Schüco LivIng

Energy costs:
Save energy costs through excellent thermal insulation up to passive house level

Freedom of design:
Various surface technologies and variable window shapes

Feel-good factor:
High feel-good factor thanks to the latest, high-quality sealing technology and optimal protection against noise, moisture and drafts for the life of the window

Security:
Security through burglary protection according to individual needs up to RC 2

Durable:
Durable, easy-care and environmentally friendly windows

The wood-aluminium windows of the LivingLine series appear discreet and of high quality thanks to their rounded aluminum shell, so that they blend harmoniously into any traditional architecture and are also suitable for the renovation of older houses. All Unilux windows only use highly robust seals made from synthetic rubber (EPDM). This is easy to clean, resistant to discoloration, durable and also hardly visible.

LivingLine 0.8 (UV VALUE 0.8 W/m2 K)

Due to the additional third pane (plus a second argon filling), the thermal insulation of the LivingLine 0.8 is significantly better than with conventional double pane insulating glazing. Thanks to its excellent price-performance ratio, the LivingLine 0.8 is the perfect choice for cool calculators.

LivingLine 0.7 (UV VALUE 0.7 W/m2 K)

In addition to a third pane, which ensures a glass thickness of almost 5 centimetres, the LivingLine 0.7 has a specially developed insulating core, a special gas filling, an invisible coating on both sides and thermally separated spacers. In this way, thermal insulation is 46% better than a standard window.

With its linear design without frills and curves, the 'ModernLine' wood-aluminium window, optionally with insulation values of 0.7 and 0.8 W/m2K, is particularly well suited for contemporary houses and buildings with an urban flair.

ModernLine 0.8 (UV VALUE 0.8 W/m2 K)

Even in the basic version with 3 panes and a second argon filling (LivingLine 0.8), the window achieves a thermal insulation value of 0.8 W/m2 K. Better than most standard double-pane insulating glazing and at a very good price/ value for money and an elegant look.

ModernLine 0.7 (UV VALUE 0.7 W/m2 K)

If you want to save even more energy, choose the ModernLine 0.7 with a specially developed insulation core, a special gas filling, an invisible coating on both sides and thermally separated spacers between the panes.

The glass thickness of this variant is almost 5 cm and with the above properties, thermal insulation can be improved by up to 46% compared to a standard window.

The 'DesignLine' model combines architectural elegance with state-of-the-art energy efficiency. This wood-aluminium window type is therefore predestined for sophisticated residential buildings and commercial properties.

DesignLine 0.8 (UV VALUE 0.8 W/m2 K)

The DesignLine 0.8 with triple glazing and argon filling impresses with its excellent price-performance ratio. Compared to normal double-pane insulating glazing, the thermal insulation is significantly better.

DesignLine 0.7 (UV VALUE 0.7 W/m2 K)

Thermal insulation at the highest level. Thermal insulation is improved by 46% compared to a standard window. This is made possible by a special insulating core, gas-filled triple insulating glass, thermally separated spacers, a two-sided (invisible) coating and a total glass thickness of 48 mm.

DesignLine Privacy

The wood-aluminium window 'DesignLine' supplemented by an integrated blind (colour selectable) results in the wood-aluminium window 'DesignLine Privacy'. The blind is integrated directly into the window, no roller shutter box is required.
